2.4G/5G AP router Network Relay WIFI Module for home gateway

Feature
◆IEEE 802.11a/b/g/n/ac WLANs
◆2.4G /5G ITIR mode
◆With support of 433Mbps PHY rate
◆IEEE 802.11e QoS Enhancement(WLAN)
◆USB LPM/Selective Suspend support
◆Fully compliance with USB2.0 High-speed mode.
◆IEEE 802.11i(WPA, WPA2). Open, shared key, and pair-wise key authentication services
◆Supports for Windows XP 32/64, 2000, Vista 32/64bit, Windows 7 32/64bit, Linux, Android
◆RoHS compliance meets nvironment-friendly requirement.
◆FCC,CE compliance

Hardware Features
Model	HS-04-W3
ANTENNA TYPE	IPEX connecter or PCB antenna
Voltage	3.5—5.5V
DIMENTIONS	36(L)x15(W)x3.2(H)mm
Wireless Features
WIRELESS STANDARDS	IEEE 802.11 a/b/g/n/ac
FREQUENCY RANGE	2.4/5GHz
DATA RATES	IEEE 802.11a Standard Mode: 6,9,12,18,24,36,48,54Mbps  IEEE 802.11 b Standard Mode: 1,2,5.5,11Mbps IEEE 802.11g Standard Mode: 6,9,12,18,24,36,48,54Mbps IEEE 802.11n/Draft 2.0 Mode: 130Mbps @ HT20 150Mbps @ HT40  IEEE 802.11ac Standard Mode: 433Mbps @VHT80
5G RECEIVE  SENSITIVITY	VHT80 MCS15: -59dBm@10% PER(MCS9) HT40 MCS15: -68dBm@10% PER(MCS7) OFDM 54M: -75dBm@10% PER OFDM 6M: -90dBm@ 8% PER
SYSTEM  REQUIREMENTS	Windows 7(32/64bits), Windows Vista(32/64bits), Windows  XP(32/64bits), Windows 2000,Linux,Android
ENVIRONMENT	Operating Temperature: -10℃~70℃ Storage Temperature: -40℃~125℃ Storage Humidity: 5%~90% non-condensing

Application set top box,smart home gateway,IP camera
